SEAL-GUARD

Premium Thread, Tubing, and Casing Compound

Specifically formulated to meet the performance requirements of proprietary, metal-to-metal seal, and high interference connection designs utilizing today's high performance materials including super chrome and high alloy steels. SEAL-GUARD's formulation uses a tightly controlled small particle size distribution and may not provide optimum sealability on buttress thread forms. SEAL-GUARD is formulated using an advanced base grease and additive technology (CZ-EX PLUS) with enhanced high and low strength polymers and innovative solid lubricants. The result is superior lubrication under high loads with galling resistance equivalent to heavy metal based compounds in a totally metal free formulation. This cutting edge technology provides a high affinity to metal surfaces with a relatively low added solids content. This formula has a large percentage of submicron particles that create a film which gives consistent frictional performance without restricting proper engagement of the connection. - Recommended for use on premium mechanical seal an 8-round connection, flow lines, nuts, bolts, etc. Can be utilized on jacking systems.

Benefits:

• Advanced base grease and additive technology
• Enhanced high & low strength polymers
• High film strength protects against galling
• Small particle solids to accommodate premium connection design requirements
• Metal-free
• H2S inhibitor
• Sticks to wet or oily threads
• Environmentally safe

Specifications:

• Base Materials: Complex / Petroleum
• Friction / Nut-Factor: 1.0 (Relative to API MODIFIED)
• Service Rating: -20°F to 450°F / -29°C to 232°C
• Certifications:
  Ospar Commission – Harmonized Offshore Chemical Notification Format (HOCNF) CLASSIFICATION: “Red” rating for Norway CLASSIFICATION: “D” for The United Kingdom and The Netherlands
  Conforms to or exceeds the requirements for API RP5A3.
  Conforms with API 5A3 for use on casing, tubing, and line pipe.
